The Dragino LDS12-LB LoRaWAN LiDAR ToF Distance Sensor provides wireless, non-contact distance and level measurement for agricultural, industrial, and environmental monitoring applications.
Using LiDAR Time-of-Flight (ToF) technology, the LDS12-LB measures the distance between the sensor and a target from 0.1 to 12 meters and transmits the measurement wirelessly over LoRaWAN. This makes it well suited for applications where continuous distance, level, proximity, or presence monitoring is needed without physical contact with the measured material or object.
The sensor can be used for tank and container level monitoring, bin and material level measurement, object detection, proximity monitoring, and other remote distance-measurement applications.
Designed for long-term IoT deployments, the LDS12-LB combines low-power LoRaWAN communication with an integrated 8500mAh battery and supports Bluetooth configuration, remote LoRaWAN configuration, battery monitoring, and wireless firmware updates.
Key Features
- LiDAR Time-of-Flight distance measurement
- Measurement range: 0.1–12 m
- Non-contact distance and level monitoring
- ±5 cm accuracy from 0.1–5 m
- ±1% accuracy from 5–12 m
- 1 cm distance resolution
- 3.6° field of view
- LoRaWAN 1.0.3 Class A
- US915 and other LoRaWAN frequency options
- Bluetooth 5.1 configuration
- Remote LoRaWAN configuration
- Wireless OTA firmware updates
- Battery-level monitoring
- Integrated 8500mAh Li-SOCl₂ battery
- IP65-rated LiDAR probe
- Designed for long-term, low-power deployments
