The XI110204 digital input module is used to acquire binary 24V control signals in a ctrlX I/O station. The module features four channels in a two-wire configuration. The signal status is indicated by the channel LED on the detachable peripheral connector.
The logic and peripheral power supply as well as the EtherCAT-based module communication are forwarded through the module.
General technical data:
- Number of outputs: 4
- Connection type: Push-in
- Connection technology: 2-wire technology
- Maximum output current: 0.5 A per channel, total current of the channels: max. 2 A. The GND contact assigned to the channel must not be loaded beyond the maximum output current of 0.5 A.
- Nominal load: Ohmic, maximum 12 W (48 Ω; at nominal voltage)
- Minimum load: 10 kΩ
- Rise time (TRise): Without load: On digital input 16.4 µs, 17.3 µs at 240 Ω, 100 mA, Resistive nominal load: 17.4 µs at 48 Ω, 500 mA
- Fall time (TFALL): Without load: On digital input 450 µs, 45.3 µs at 240 Ω, 100 mA, Resistive nominal load: 22.4 µs at 48 Ω, 500 mA
- Inductive shutdown energy: Maximum 150 mJ
- Behavior in case of overload: Channel-granular shutdown with automatic restart
- Regeneration protection: Not regeneration proof, external precautions necessary
- Nominal voltage (UL/UP): DC 24 V (19.2 V to 30 V, including tolerance and residual ripple) PELV/SELV (safety extra-low voltage)
- Current consumption UL: 30 mA
- Current consumption UP: 15 mA + load
- Maximum power consumption of the module: 1 W
- Bit width in the process image: 4 bits
- Configuration: No address or configuration setting required
- Dimensions: 12 mm × 105 mm × 99 mm (width × height × depth)
- Weight: 90 g (module including plug)
- Potential isolation: DC 1200 V UP to UL, DC 707 V UP/UL to FE, tested for 60 s each (not evaluated by UL)
- EMC immunity: According to EN 61000-6-2 and EN 61000-6-4
- Installation position: Vertical, on a horizontal mounting rail
- Marking, approvals: CE, UKCA, UL
